TECHNYL® 4EARTH® A1E 218 V30 BK H
30% Glass Fiber Reinforced Sustainable PA66 · Recycled Source · Heat Stabilized · Black Color
♻️ Recycled Source
Heat Stabilized
Automotive Applications
Glass Fiber
Recycled Source
Tensile Modulus (MPa)
HDT (°C @ 1.8MPa)
TECHNYL® 4EARTH® A1E 218 V30 BK H (previously TECHNYL 4EARTH A4E 218 V30 BLACK) is a 30% glass fiber reinforced sustainable polyamide 66 (PA66) grade from recycled source, heat stabilized, specifically developed for injection molding. This grade maintains excellent mechanical and thermal properties while significantly reducing environmental footprint, making it an ideal sustainable material choice for automotive applications.
📋 Product Overview
- Polymer Type: PA66 (Polyamide 66)
- Reinforcement: 30% Glass Fiber
- Sustainability Feature: Recycled Source
- Heat Stabilized: Yes
- Processing: Injection Molding
- Color: Black
- Certifications: RoHS, REACH, UL Yellow Card
- Typical Applications: Automotive Applications
📊 Technical Data Sheet
Physical Properties
Mechanical Properties (DAM / Conditioned)
Thermal Properties
Flammability
✅ UL Yellow Card available (QMFZ2.E44716)
♻️ Sustainability · Core Value of 4EARTH Series
TECHNYL® 4EARTH® series is DOMO Chemicals’ flagship sustainable polyamide product line. A1E 218 V30 BK H offers the following sustainability features:
- Recycled Source: Uses post-consumer/post-industrial recycled materials, reducing resource consumption
- Reduced Carbon Footprint: Significantly lower carbon footprint compared to virgin PA66-GF30
- Performance Equivalence: Mechanical and thermal properties comparable to virgin materials
- Heat Stabilized: Suitable for long-term thermal aging applications
- Automotive Qualified: Meets demanding automotive industry requirements
⚙️ Processing Conditions
80°C / 2-4 hours
Dew point ≥ -20°C
0.2%
270 – 280°C
275 – 285°C
280 – 290°C
70 – 100°C
(Up to 120°C for high surface quality)
The material is supplied in airtight bags, ready for use. If the virgin material has absorbed moisture, it must be dried with dehumidified air drying equipment (dew point minimum -20°C). Recommended drying time: 2-4 hours.
For reinforced polyamides, DOMO recommends using steel with high carbon content, purified for polishing, to avoid or limit abrasion. For example: X38CrMoV5-1 (EN Norm) – 1.2367/1.2343 (DIN Norm) or X160CrMoV12 – 1.2601/1.2379 (DIN Norm).
🎯 Target Applications
Engine surroundings, brackets
Pump bodies, gears, bearings
Parts requiring environmental certification
🔗 Related Products
📎 Download & Support
※ Click download links to access the complete technical datasheet. For any questions, please contact us.
Disclaimer: The information provided in this documentation corresponds to our technical knowledge at the date of its publication and does not constitute a specification. DOMO cannot anticipate all conditions under which this information and our products may be used. Users are advised to make their own tests to determine the safety and suitability for their own purposes. Unless otherwise agreed in writing, DOMO sells the product without warranties. Unless specifically indicated, this grade is not suitable for pharmaceutical/medical applications.
Source: DOMO Chemicals Official Technical Data Sheet (TECHNYL 4EARTH A1E 218 V30 BK H, previously TECHNYL 4EARTH A4E 218 V30 BLACK, Document 001526)
Last Updated: June 2026
